Running containers with Colima

A container is a way to run software under some constraints, that takes advantage of some operating system features to isolate and control its usage of resources, while still running on the same operating system. Containers can help you to:

• Isolate what runs in the container from the outside world and sharing only what is needed
• Control the resources used by the processes that run in the container
• Avoid problems with dependencies required to run the software of the container
• Avoid littering the disk of your computer with code that you just want to try
• And, in general, address the situation where one could say: "it runs on my machine"

In principle, containers could be run on any operating system, but the truth is that some features that have to be provided by the OS aren't available, either partially or completely, for every operating system. Containers use Linux namespaces in order to achieve isolation and control. And, although, macOS offers a related feature called App Sandbox, it aims mostly at restricting the application access to certain parts of the file system, some sensitive data and attached hardware and the network. So, it wouldn't be trivial to implement an application that runs containers natively in macOS using just those features.

What we can do instead is to use a virtual machine. A virtual machine provides isolation too, but in a very different way. It shares the hardware splitting its usage and each virtual machine requires running a full instance of the operating system within it. This approach achieves better isolation and control, but requires more resources, at the very least those used to run the operating system for each virtual machine. That includes dedicating a part of the RAM to run that virtual machine and that stops been available for the main system. Virtual machines are a great option, but when you want to run several isolated applications, the overhead adds up very fast.

However, we can combine virtual machines and containers. We can create a virtual machine that runs an instance of Linux –with only the essential parts– and use the capabilities of that Linux instance to run containers. We will need to choose the amount of memory dedicated to that virtual machine, and run in it the container engine run-time –the software that takes care of everything related to the containers.

There are many things we can do with the containers running in a virtual machine. Still, when you run a virtual machine, the hardware used by that virtual machine is the same one that your actual machine has. I mean, if you run a virtual machine in an Intel Mac, the virtual machine will be able to run an operating system and other software produced for that architecture, but not for Apple Silicon. The same happens the other way around: you cannot directly run containers created for the intel architecture –the most abundant ones– using a virtual machine running in your arm64 system. If you want to run software for a different architecture, then you need an emulator. An emulator is an application that runs software created for a different architecture than the one you use.

Colima –Containers on Lima– uses Lima –Linux Machines– to launch the virtual machine it needs. Lima supports two different virtualization technologies: vz and qemu. Since macOS 11, the vz virtualization framework is included in the system, but for Lima, we need to be running macOS 13.5+. We can use vz when we want to have a virtual machine with same architecture of our system. Alternatively, Qemu is a machine emulator, hence it can run amd64 binaries in an arm64 Apple Silicon system. There is another amd64 emulator available for Macs with Apple Silicon CPUs, this one provided by Apple; it is called Rosetta. Both Qemu and Rosetta can run Intel binaries in an Apple Silicon CPU, but Qemu emulates the whole system, while Rosetta works at the process level translating the opcodes of the Intel binary to get it to run as any other arm64 process on that machine. So Rosetta is more restrictive, but faster than Qemu.

Finally, a word on sharing data between the virtual machine, the containers and your macOS. You can use virtiofs, 9p or SSHFS. virtiofs is the preferred option and the fastest for macOS. If you use Qemu, then 9p is more stable, but slower, while SSHFS, that uses the SSH server of to provide SFTP and shows the contents as a mounted directory, is faster, but less reliable when there are many concurrent reads or writes.

So, if you are using an Intel mac, you should use Colima with vz virtualization and nothing else. Almost all containers are released for amd64 –aka x86_64–, so you won't have any problems. If you, like me, use an arm64 Mac instead, then, you can still use vz virtualization to run a light-weight Linux for arm64 and take advantage of Rosetta to run the amd64. You could use Qemu to run Linux for amd64 in the virtual machine, but that would be much slower.

Before we start installing Colima, we should ensure that you have Rosetta available in your system:

  softwareupdate --install-rosetta

Then, I am going to use brew to install the required software :

  brew install colima docker docker-compose

Notice that we aren't installing qemu, because will be using vz for the virtual machine and Rosetta for the amd64 containers.

Now that everything is installed, we can start Colima. We can do it by entering the following command, where we specify the virtualization type and the file system type, enable Rosetta, and customize the number of CPUs and the memory dedicated to the virtual machine:

  colima start --vm-type vz --vz-rosetta --mount-type virtiofs --cpu 4 --memory 8

Or, set the proper configuration in $HOME/.colima/default/colima.yaml and start the virtual machine, with:

  colima start --edit

If you use the latter, double check that you have all the options mentioned above.

At any moment you should be able to query the status of the virtual machine with:

  colima status

For an arm64 Mac, the architecture should be aarch64.

When you don't need the virtual machine and the containers running, you can stop it with:

  colima stop

If you want to get rid of the current virtual machine and its configuration, you can use the following command:

  colima delete

We are going to run the linux/arm64 version of the Oracle Database 23ai Free Container Image. This should be trivial, since we are running a container that was built for the architecture that we have.

The command is very simple:

  docker run -d \
  -p 1521:1521 \
  -e ORACLE_PWD='0pen-S3sam3.' \
  --name db-free \
  --platform linux/arm64 \
  container-registry.oracle.com/database/free:latest

You can use container management commands to check that it is running (docker ps). The container is ready to be used when docker log -f db-free shows the message: "DATABASE IS READY TO USE!"

Oracle's Autonomous Database 23ai free container is currently only available for the amd64 architecture. We can use this free container to develop software that talks to the database, learn how to use the different functionalities that it offers or connecting it other software among many other things.

We are going to start by downloading the image for the Oracle's Autonomous Database 23ai container.

  docker pull container-registry.oracle.com/database/adb-free:latest-23ai

Notice that if we change this command to request the image for the arm64 architecture:

  docker pull --platform linux/aarch64 container-registry.oracle.com/database/adb-free:latest-23ai

it will show an error because it isn't available for that platform:

image with reference container-registry.oracle.com/database/adb-free:latest-23ai was found but its platform (linux/amd64) does not match the specified platform (linux/arm64)

Since we have Rosetta available, we can run the image of the intel container with:

  docker run -d \
  -p 1521:1522 \
  -p 1522:1522 \
  -p 8443:8443 \
  -p 27017:27017 \
  -e WORKLOAD_TYPE='ATP' \
  -e WALLET_PASSWORD='Wa((3t_pass' \
  -e ADMIN_PASSWORD='0pen-S3sam3.' \
  --cap-add SYS_ADMIN \
  --device /dev/fuse \
  --name adb-free \
  container-registry.oracle.com/database/adb-free:latest-23ai

It will give us a warning ("WARNING: The requested image's platform (linux/amd64) does not match the detected host platform (linux/arm64/v8) and no specific platform was requested"), but it will return the container ID. If you add the option --platform linux/amd64, the error is not shown.

The Oracle Autonomous Database Free Container is ready to use when docker log -f adb-free shows the status of the listener.
